BRL-CAD: include/vmath.h File Reference

Go to the source code of this file.


Defines
#define	VMATH_H seen
#define	M_E 2.7182818284590452354
#define	M_LOG2E 1.4426950408889634074
#define	M_LOG10E 0.43429448190325182765
#define	M_LN2 0.69314718055994530942
#define	M_LN10 2.30258509299404568402
#define	M_PI 3.14159265358979323846
#define	M_PI_2 1.57079632679489661923
#define	M_PI_4 0.78539816339744830962
#define	M_1_PI 0.31830988618379067154
#define	M_2_PI 0.63661977236758134308
#define	M_2_SQRTPI 1.12837916709551257390
#define	M_SQRT2 1.41421356237309504880
#define	M_SQRT1_2 0.70710678118654752440
#define	M_SQRT2_DIV2 0.70710678118654752440
#define	PI M_PI
#define	VDIVIDE_TOL ( 1.0e-20 )
#define	VUNITIZE_TOL ( 1.0e-15 )
#define	ELEMENTS_PER_VECT 3
	# of fastf_t's per vect_t
#define	ELEMENTS_PER_PT 3
#define	HVECT_LEN 4
	# of fastf_t's per hvect_t
#define	HPT_LEN 4
#define	ELEMENTS_PER_PLANE 4
	# of fastf_t's per plane_t
#define	ELEMENTS_PER_MAT (4*4)
#define	quat_t hvect_t
	4-element quaternion
#define	NEAR_ZERO(val, epsilon) ( ((val) > -epsilon) && ((val) < epsilon) )
#define	CLAMP(_v, _l, _h) if ((_v) < (_l)) _v = _l; else if ((_v) > (_h)) _v = _h
#define	DIST_PT_PLANE(_pt, _pl) (VDOT(_pt, _pl) - (_pl)[H])
	Compute distance from a point to a plane.
#define	DIST_PT_PT(a, b)
	Compute distance between two points.
#define	X 0
#define	Y 1
#define	Z 2
#define	H 3
#define	W H
#define	MDX 3
#define	MDY 7
#define	MDZ 11
#define	MAT_DELTAS(m, x, y, z)
	set translation values of 4x4 matrix with x, y, z values
#define	MAT_DELTAS_VEC(_m, _v) MAT_DELTAS(_m, (_v)[X], (_v)[Y], (_v)[Z] )
	set translation values of 4x4 matrix from a vector
#define	MAT_DELTAS_VEC_NEG(_m, _v) MAT_DELTAS(_m,-(_v)[X],-(_v)[Y],-(_v)[Z] )
	set translation values of 4x4 matrix from a reversed vector
#define	MAT_DELTAS_GET(_v, _m)
	get translation values of 4x4 matrix to a vector
#define	MAT_DELTAS_GET_NEG(_v, _m)
	get translation values of 4x4 matrix to a vector, reversed
#define	MSX 0
#define	MSY 5
#define	MSZ 10
#define	MSA 15
#define	MAT_SCALE(_m, _x, _y, _z)
	set scale of 4x4 matrix from xyz
#define	MAT_SCALE_VEC(_m, _v)
	set scale of 4x4 matrix from vector
#define	MAT_SCALE_ALL(_m, _s) (_m)[MSA] = (_s)
	set uniform scale of 4x4 matrix from scalar
#define	MAT_ZERO(m)
	zero a matrix
#define	MAT_IDN(m)
	set matrix to identity
#define	MAT_COPY(d, s)
	copy a matrix
#define	VSET(a, b, c, d)
	Set vector at `a' to have coordinates `b', `c', `d'.
#define	VSETALL(a, s) { (a)[X] = (a)[Y] = (a)[Z] = (s); }
	Set all elements of vector to same scalar value.
#define	VSETALLN(v, s, n)
	Set all elements of N-vector to same scalar value.
#define	VMOVE(a, b)
	Transfer vector at `b' to vector at `a'.
#define	VMOVEN(a, b, n)
	Transfer vector of length `n' at `b' to vector at `a'.
#define	HMOVE(a, b)
	Move a homogeneous 4-tuple.
#define	V2MOVE(a, b)
	move a 2D vector. This naming convention seems better than the VMOVE_2D version below
#define	VREVERSE(a, b)
	Reverse the direction of vector b and store it in a.
#define	HREVERSE(a, b)
	Same as VREVERSE, but for a 4-tuple. Also useful on plane_t objects.
#define	VADD2(a, b, c)
	Add vectors at `b' and `c', store result at `a'.
#define	VADD2N(a, b, c, n)
	Add vectors of length `n' at `b' and `c', store result at `a'.
#define	V2ADD2(a, b, c)
#define	VSUB2(a, b, c)
	Subtract vector at `c' from vector at `b', store result at `a'.
#define	VSUB2N(a, b, c, n)
	Subtract `n' length vector at `c' from vector at `b', store result at `a'.
#define	V2SUB2(a, b, c)
#define	VSUB3(a, b, c, d)
	Vectors: A = B - C - D.
#define	VSUB3N(a, b, c, d, n)
	Vectors: A = B - C - D for vectors of length `n'.
#define	VADD3(a, b, c, d)
	Add 3 vectors at `b', `c', and `d', store result at `a'.
#define	VADD3N(a, b, c, d, n)
	Add 3 vectors of length `n' at `b', `c', and `d', store result at `a'.
#define	VADD4(a, b, c, d, e)
	Add 4 vectors at `b', `c', `d', and `e', store result at `a'.
#define	VADD4N(a, b, c, d, e, n)
	Add 4 `n' length vectors at `b', `c', `d', and `e', store result at `a'.
#define	VSCALE(a, b, c)
	Scale vector at `b' by scalar `c', store result at `a'.
#define	HSCALE(a, b, c)
#define	VSCALEN(a, b, c, n)
	Scale vector of length `n' at `b' by scalar `c', store result at `a'.
#define	V2SCALE(a, b, c)
#define	VUNITIZE(a)
	Normalize vector `a' to be a unit vector.
#define	VUNITIZE_RET(a, ret)
	If vector magnitude is too small, return an error code.
#define	VADD2SCALE(o, a, b, s)
	Find the sum of two points, and scale the result. Often used to find the midpoint.
#define	VADD2SCALEN(o, a, b, n)
#define	VSUB2SCALE(o, a, b, s)
	Find the difference between two points, and scale result. Often used to compute bounding sphere radius given rpp points.
#define	VSUB2SCALEN(o, a, b, n)
#define	VCOMB3(o, a, b, c, d, e, f)
	Combine together several vectors, scaled by a scalar.
#define	VCOMB3N(o, a, b, c, d, e, f, n)
#define	VCOMB2(o, a, b, c, d)
#define	VCOMB2N(o, a, b, c, d, n)
#define	VJOIN4(a, b, c, d, e, f, g, h, i, j)
#define	VJOIN3(a, b, c, d, e, f, g, h)
#define	VJOIN2(a, b, c, d, e, f)
	Compose vector at `a' of: Vector at `b' plus scalar `c' times vector at `d' plus scalar `e' times vector at `f'.
#define	VJOIN2N(a, b, c, d, e, f, n)
#define	VJOIN1(a, b, c, d)
#define	VJOIN1N(a, b, c, d, n)
#define	HJOIN1(a, b, c, d)
#define	V2JOIN1(a, b, c, d)
#define	VBLEND2(a, b, c, d, e)
	Blend into vector `a' scalar `b' times vector at `c' plus scalar `d' times vector at `e'.
#define	VBLEND2N(a, b, c, d, e, n)
#define	MAGSQ(a) ( (a)[X](a)[X] + (a)[Y](a)[Y] + (a)[Z]*(a)[Z] )
	Return scalar magnitude squared of vector at `a'.
#define	MAG2SQ(a) ( (a)[X](a)[X] + (a)[Y](a)[Y] )
#define	MAGNITUDE(a) sqrt( MAGSQ( a ) )
	Return scalar magnitude of vector at `a'.
#define	VCROSS(a, b, c)
	Store cross product of vectors at `b' and `c' in vector at `a'. Note that the "right hand rule" applies: If closing your right hand goes from `b' to `c', then your thumb points in the direction of the cross product.
#define	VDOT(a, b) ( (a)[X](b)[X] + (a)[Y](b)[Y] + (a)[Z]*(b)[Z] )
	Compute dot product of vectors at `a' and `b'.
#define	V2DOT(a, b) ( (a)[X](b)[X] + (a)[Y](b)[Y] )
#define	VSUB2DOT(_pt2, _pt, _vec)
	Subtract two points to make a vector, dot with another vector.
#define	V2ARGS(a) (a)[X], (a)[Y]
	Turn a vector into comma-separated list of elements, for subroutine args.
#define	V3ARGS(a) (a)[X], (a)[Y], (a)[Z]
#define	V4ARGS(a) (a)[X], (a)[Y], (a)[Z], (a)[W]
#define	V2INTCLAMPARGS(a) INTCLAMP((a)[X]), INTCLAMP((a)[Y])
	integer clamped versions of the previous arg macros
#define	V3INTCLAMPARGS(a) INTCLAMP((a)[X]), INTCLAMP((a)[Y]), INTCLAMP((a)[Z])
	integer clamped versions of the previous arg macros
#define	V4INTCLAMPARGS(a) INTCLAMP((a)[X]), INTCLAMP((a)[Y]), INTCLAMP((a)[Z]), INTCLAMP((a)[W])
	integer clamped versions of the previous arg macros
#define	V2PRINT(a, b) (void)fprintf(stderr,"%s (%g, %g)\n", a, V2ARGS(b) );
	Print vector name and components on stderr.
#define	VPRINT(a, b) (void)fprintf(stderr,"%s (%g, %g, %g)\n", a, V3ARGS(b) );
#define	HPRINT(a, b) (void)fprintf(stderr,"%s (%g, %g, %g, %g)\n", a, V4ARGS(b) );
#define	V2INTCLAMPPRINT(a, b) (void)fprintf(stderr,"%s (%g, %g)\n", a, V2INTCLAMPARGS(b) );
	integer clamped versions of the previous print macros
#define	VINTCLAMPPRINT(a, b) (void)fprintf(stderr,"%s (%g, %g, %g)\n", a, V3INTCLAMPARGS(b) );
#define	HINTCLAMPPRINT(a, b) (void)fprintf(stderr,"%s (%g, %g, %g, %g)\n", a, V4INTCLAMPARGS(b) );
#define	INTCLAMP(_a) ( NEAR_ZERO((_a) - rint(_a), VUNITIZE_TOL) ? rint(_a) : (_a) )
#define	VELMUL(a, b, c)
	Vector element multiplication. Really: diagonal matrix X vect.
#define	VELMUL3(a, b, c, d)
#define	VELDIV(a, b, c)
	Similar to VELMUL.
#define	VINVDIR(_inv, _dir)
	Given a direction vector, compute the inverses of each element. When division by zero would have occured, mark inverse as INFINITY.
#define	MAT3X3VEC(o, mat, vec)
	Apply the 3x3 part of a mat_t to a 3-tuple. This rotates a vector without scaling it (changing its length).
#define	VEC3X3MAT(o, i, m)
	Multiply a 3-tuple by the 3x3 part of a mat_t.
#define	MAT3X2VEC(o, mat, vec)
	Apply the 3x3 part of a mat_t to a 2-tuple (Z part=0).
#define	VEC2X3MAT(o, i, m)
	Multiply a 2-tuple (Z=0) by the 3x3 part of a mat_t.
#define	MAT4X3PNT(o, m, i)
	Apply a 4x4 matrix to a 3-tuple which is an absolute Point in space.
#define	PNT3X4MAT(o, i, m)
	Multiply an Absolute 3-Point by a full 4x4 matrix.
#define	MAT4X4PNT(o, m, i)
	Multiply an Absolute hvect_t 4-Point by a full 4x4 matrix.
#define	MAT4X3VEC(o, m, i)
	Apply a 4x4 matrix to a 3-tuple which is a relative Vector in space This macro can scale the length of the vector if [15] != 1.0.
#define	MAT4XSCALOR(o, m, i) {(o) = (i) / (m)[15];}
#define	VEC3X4MAT(o, i, m)
	Multiply a Relative 3-Vector by most of a 4x4 matrix.
#define	VEC2X4MAT(o, i, m)
	Multiply a Relative 2-Vector by most of a 4x4 matrix.
#define	BN_VEC_NON_UNIT_LEN(_vec) (fabs(MAGSQ(_vec)) < 0.0001 \|\| fabs(fabs(MAGSQ(_vec))-1) > 0.0001)
	Test a vector for non-unit length.
#define	VEQUAL(a, b) ((a)[X]==(b)[X] && (a)[Y]==(b)[Y] && (a)[Z]==(b)[Z])
	Compare two vectors for EXACT equality. Use carefully.
#define	VAPPROXEQUAL(a, b, tol)
	Compare two vectors for approximate equality, within the specified absolute tolerance.
#define	VNEAR_ZERO(v, tol)
	Test for all elements of `v' being smaller than `tol'.
#define	V_MIN(r, s) if( (s) < (r) ) r = (s)
	Macros to update min and max X,Y,Z values to contain a point.
#define	V_MAX(r, s) if( (s) > (r) ) r = (s)
#define	VMIN(r, s) { V_MIN((r)[X],(s)[X]); V_MIN((r)[Y],(s)[Y]); V_MIN((r)[Z],(s)[Z]); }
#define	VMAX(r, s) { V_MAX((r)[X],(s)[X]); V_MAX((r)[Y],(s)[Y]); V_MAX((r)[Z],(s)[Z]); }
#define	VMINMAX(min, max, pt) { VMIN( (min), (pt) ); VMAX( (max), (pt) ); }
#define	HDIVIDE(a, b)
	Divide out homogeneous parameter from hvect_t, creating vect_t.
#define	VADD2_2D(a, b, c) V2ADD2(a,b,c)
	Some 2-D versions of the 3-D macros given above.
#define	VSUB2_2D(a, b, c) V2SUB2(a,b,c)
#define	MAGSQ_2D(a) MAG2SQ(a)
#define	VDOT_2D(a, b) V2DOT(a,b)
#define	VMOVE_2D(a, b) V2MOVE(a,b)
#define	VSCALE_2D(a, b, c) V2SCALE(a,b,c)
#define	VJOIN1_2D(a, b, c, d) V2JOIN1(a,b,c,d)
#define	QUAT_FROM_ROT(q, r, x, y, z)
	Quaternion math definitions.Create Quaternion from Vector and Rotation about vector.
#define	QUAT_FROM_VROT(q, r, v)
#define	QUAT_FROM_VROT_DEG(q, r, v) QUAT_FROM_VROT(q, ((r)*(M_PI/180.0)), v)
#define	QUAT_FROM_ROT_DEG(q, r, x, y, z) QUAT_FROM_ROT(q, ((r)*(M_PI/180.0)), x, y, z)
#define	QSET(a, b, c, d, e)
	Set quaternion at `a' to have coordinates `b', `c', `d', `e'.
#define	QMOVE(a, b)
	Transfer quaternion at `b' to quaternion at `a'.
#define	QADD2(a, b, c)
	Add quaternions at `b' and `c', store result at `a'.
#define	QSUB2(a, b, c)
	Subtract quaternion at `c' from quaternion at `b', store result at `a'.
#define	QSCALE(a, b, c)
	Scale quaternion at `b' by scalar `c', store result at `a'.
#define	QUNITIZE(a)
	Normalize quaternion 'a' to be a unit quaternion.
#define	QMAGSQ(a)
	Return scalar magnitude squared of quaternion at `a'.
#define	QMAGNITUDE(a) sqrt( QMAGSQ( a ) )
	Return scalar magnitude of quaternion at `a'.
#define	QDOT(a, b)
	Compute dot product of quaternions at `a' and `b'.
#define	QMUL(a, b, c)
	Compute quaternion product a = b * c a[W] = b[W]*c[W] - VDOT(b,c); VCROSS( temp, b, c ); VJOIN2( a, temp, b[W], c, c[W], b );.
#define	QCONJUGATE(a, b)
	Conjugate quaternion.
#define	QINVERSE(a, b)
	Multiplicative inverse quaternion.
#define	QBLEND2(a, b, c, d, e)
	Blend into quaternion `a' scalar `b' times quaternion at `c' plus scalar `d' times quaternion at `e'.
#define	V3RPP_DISJOINT(_l1, _h1, _l2, _h2)
	Macros for dealing with 3-D "extents" represented as axis-aligned right parallelpipeds (RPPs). This is stored as two points: a min point, and a max point. RPP 1 is defined by lo1, hi1, RPP 2 by lo2, hi2. Compare two extents represented as RPPs. If they are disjoint, return true.
#define	V3RPP_OVERLAP(_l1, _h1, _l2, _h2)
	Compare two extents represented as RPPs. If they overlap, return true.
#define	V3RPP_OVERLAP_TOL(_l1, _h1, _l2, _h2, _t)
	If two extents overlap within distance tolerance, return true.
#define	V3PT_IN_RPP(_pt, _lo, _hi)
	Is the point within or on the boundary of the RPP?
#define	V3PT_IN_RPP_TOL(_pt, _lo, _hi, _t)
	Within the distance tolerance, is the point within the RPP?
#define	V3RPP1_IN_RPP2(_lo1, _hi1, _lo2, _hi2)
	Determine if one bounding box is within another. Also returns true if the boxes are the same.
Typedefs
typedef fastf_t	mat_t [ELEMENTS_PER_MAT]
	4x4 matrix
typedef fastf_t *	matp_t
typedef fastf_t	vect_t [ELEMENTS_PER_VECT]
	3-tuple vector
typedef fastf_t *	vectp_t
typedef fastf_t	point_t [ELEMENTS_PER_PT]
	3-tuple point
typedef fastf_t *	pointp_t
typedef fastf_t	point2d_t [2]
typedef fastf_t	hvect_t [HVECT_LEN]
	4-tuple vector
typedef fastf_t	hpoint_t [HPT_LEN]
	4-tuple point
typedef fastf_t	plane_t [ELEMENTS_PER_PLANE]
	Definition of a plane equation.

Detailed Description

This header file defines many commonly used 3D vector math macros, and operates on vect_t, point_t, mat_t, and quat_t objects.

Note that while many people in the computer graphics field use post-multiplication with row vectors (ie, vector * matrix * matrix ...) the BRL-CAD system uses the more traditional representation of column vectors (ie, ... matrix * matrix * vector). (The matrices in these two representations are the transposes of each other). Therefore, when transforming a vector by a matrix, pre-multiplication is used, ie:

                vec'  =  T1 * vec
                vec'' =  T2 * T1 * vec  =  T2 * vec'

The most notable implication of this is the location of the "delta" (translation) values in the matrix, ie:

        x'     ( R0   R1   R2   Dx )      x
        y' =   ( R4   R5   R6   Dy )   *  y
        z'     ( R8   R9   R10  Dz )      z
        w'     (  0    0    0   1/s)      w

When writing macros like this, it is very important that any variables which are declared within code blocks inside a macro start with an underscore. This prevents any name conflicts with user-provided parameters. For example: { register double _f; stuff; }

        #include <stdio.h>
        #include <math.h>
        #include "machine.h"    /_* For fastf_t definition on this machine *_/
        #include "vmath.h"

vmath.h File Reference

Defines

Typedefs

Detailed Description
