Polynomials
[libbn (numerical functions)]

Collaboration diagram for Polynomials:


Files
file	poly.c
Data Structures
struct	bn_poly
Defines
#define	BN_MAX_POLY_DEGREE 4
#define	BN_POLY_MAGIC 0x506f4c79
#define	BN_CK_POLY(_p) BU_CKMAG(_p, BN_POLY_MAGIC, "struct bn_poly")
#define	BN_POLY_NULL ((struct bn_poly *)NULL)
#define	Abs(a) ((a) >= 0 ? (a) : -(a))
#define	Max(a, b) ((a) > (b) ? (a) : (b))
#define	M_PI 3.14159265358979323846
#define	PI_DIV_3 (M_PI/3.0)
#define	SQRT3 1.732050808
#define	THIRD 0.333333333333333333333333333
#define	INV_TWENTYSEVEN 0.037037037037037037037037037
#define	CUBEROOT(a) (( (a) >= 0.0 ) ? pow( a, THIRD ) : -pow( -(a), THIRD ))
Typedefs
typedef bn_poly	bn_poly_t
Functions
bn_poly *	bn_poly_mul (struct bn_poly product, const struct bn_poly m1, const struct bn_poly *m2)
bn_poly *	bn_poly_scale (struct bn_poly *eqn, double factor)
bn_poly *	bn_poly_add (struct bn_poly sum, const struct bn_poly poly1, const struct bn_poly *poly2)
bn_poly *	bn_poly_sub (struct bn_poly diff, const struct bn_poly poly1, const struct bn_poly *poly2)
void	bn_poly_synthetic_division (struct bn_poly quo, struct bn_poly rem, const struct bn_poly dvdend, const struct bn_poly dvsor)
int	bn_poly_quadratic_roots (struct bn_complex roots[], const struct bn_poly *quadrat)
int	bn_poly_cubic_roots (struct bn_complex roots[], const struct bn_poly *eqn)
int	bn_poly_quartic_roots (struct bn_complex roots[], const struct bn_poly *eqn)
void	bn_pr_poly (const char title, const struct bn_poly eqn)
void	bn_pr_roots (const char *title, const struct bn_complex roots[], int n)
bn_poly *	bn_poly_mul (register struct bn_poly product, register const struct bn_poly m1, register const struct bn_poly *m2)
	multiply two polynomials
bn_poly *	bn_poly_scale (register struct bn_poly *eqn, double factor)
	scale a polynomial
bn_poly *	bn_poly_add (register struct bn_poly sum, register const struct bn_poly poly1, register const struct bn_poly *poly2)
	add two polynomials
bn_poly *	bn_poly_sub (register struct bn_poly diff, register const struct bn_poly poly1, register const struct bn_poly *poly2)
	subtract two polynomials
void	bn_poly_synthetic_division (register struct bn_poly quo, register struct bn_poly rem, register const struct bn_poly dvdend, register const struct bn_poly dvsor)
	Divides any polynomial into any other polynomial using synthetic division. Both polynomials must have real coefficients.
int	bn_poly_quadratic_roots (register struct bn_complex roots, register const struct bn_poly quadrat)
	Uses the quadratic formula to find the roots (in `complex' form) of any quadratic equation with real coefficients.
HIDDEN void	bn_catch_FPE (int sig)
int	bn_poly_cubic_roots (register struct bn_complex roots, register const struct bn_poly eqn)
int	bn_poly_quartic_roots (register struct bn_complex roots, register const struct bn_poly eqn)
	Uses the quartic formula to find the roots ( in `complex' form ) of any quartic equation with real coefficients.
void	bn_pr_poly (const char title, register const struct bn_poly eqn)
void	bn_pr_roots (const char title, const struct bn_complex roots, int n)

Define Documentation

#define BN_MAX_POLY_DEGREE 4

Definition at line 895 of file bn.h.
Referenced by bn_poly_mul().

#define BN_POLY_MAGIC 0x506f4c79

Definition at line 904 of file bn.h.
Referenced by bu_identify_magic().

#define BN_CK_POLY ( _p ) BU_CKMAG(_p, BN_POLY_MAGIC, "struct bn_poly")

Definition at line 905 of file bn.h.

#define BN_POLY_NULL ((struct bn_poly *)NULL)

Definition at line 906 of file bn.h.
Referenced by bn_poly_mul().

#define Abs ( a ) ((a) >= 0 ? (a) : -(a))

Definition at line 53 of file poly.c.
Referenced by bn_poly_add(), bn_poly_cubic_roots(), bn_poly_quartic_roots(), and bn_poly_sub().

#define Max ( a,
b ) ((a) > (b) ? (a) : (b))

Definition at line 54 of file poly.c.

#define M_PI 3.14159265358979323846

Definition at line 57 of file poly.c.

#define PI_DIV_3 (M_PI/3.0)

Definition at line 59 of file poly.c.
Referenced by bn_poly_cubic_roots().

#define SQRT3 1.732050808

Definition at line 275 of file poly.c.
Referenced by bn_poly_cubic_roots().

#define THIRD 0.333333333333333333333333333

Definition at line 276 of file poly.c.
Referenced by bn_poly_cubic_roots().

#define INV_TWENTYSEVEN 0.037037037037037037037037037

Definition at line 277 of file poly.c.
Referenced by bn_poly_cubic_roots().

#define CUBEROOT ( a ) (( (a) >= 0.0 ) ? pow( a, THIRD ) : -pow( -(a), THIRD ))

Definition at line 278 of file poly.c.
Referenced by bn_poly_cubic_roots().

Typedef Documentation

typedef struct bn_poly bn_poly_t

Polynomial data type

Function Documentation

struct bn_poly* bn_poly_mul ( struct bn_poly * product,

const struct bn_poly * m1,

const struct bn_poly * m2

)

struct bn_poly* bn_poly_scale ( struct bn_poly * eqn,

double factor

)

struct bn_poly* bn_poly_add ( struct bn_poly * sum,

const struct bn_poly * poly1,

const struct bn_poly * poly2

)

struct bn_poly* bn_poly_sub ( struct bn_poly * diff,

const struct bn_poly * poly1,

const struct bn_poly * poly2

)

void bn_poly_synthetic_division ( struct bn_poly * quo,

struct bn_poly * rem,

const struct bn_poly * dvdend,

const struct bn_poly * dvsor

)

int bn_poly_quadratic_roots ( struct bn_complex roots[],

const struct bn_poly * quadrat

)

Referenced by bn_poly_quartic_roots().

int bn_poly_cubic_roots ( struct bn_complex roots[],

const struct bn_poly * eqn

)

Referenced by bn_poly_quartic_roots().

int bn_poly_quartic_roots ( struct bn_complex roots[],

const struct bn_poly * eqn

)

void bn_pr_poly ( const char * title,

const struct bn_poly * eqn

)

void bn_pr_roots ( const char * title,

const struct bn_complex roots[],

int n

)

Referenced by bend_pipe_shot(), rt_eto_shot(), rt_superell_shot(), and rt_tor_shot().

struct bn_poly* bn_poly_mul ( register struct bn_poly * product,

register const struct bn_poly * m1,

register const struct bn_poly * m2

)

multiply two polynomials
bn_poly_mul
Definition at line 69 of file poly.c.
References BN_MAX_POLY_DEGREE, BN_POLY_NULL, and bn_poly::dgr.

struct bn_poly* bn_poly_scale ( register struct bn_poly * eqn,

double factor

)

scale a polynomial
bn_poly_scale
Definition at line 123 of file poly.c.
References bn_poly::cf.

struct bn_poly* bn_poly_add ( register struct bn_poly * sum,

register const struct bn_poly * poly1,

register const struct bn_poly * poly2

)

add two polynomials
bn_poly_add
Definition at line 140 of file poly.c.
References Abs, bn_poly::cf, and LOCAL.

struct bn_poly* bn_poly_sub ( register struct bn_poly * diff,

register const struct bn_poly * poly1,

register const struct bn_poly * poly2

)

subtract two polynomials
bn_poly_sub
Definition at line 174 of file poly.c.
References Abs, bn_poly::cf, and LOCAL.

void bn_poly_synthetic_division ( register struct bn_poly * quo,

register struct bn_poly * rem,

register const struct bn_poly * dvdend,

register const struct bn_poly * dvsor

)

Divides any polynomial into any other polynomial using synthetic division. Both polynomials must have real coefficients.
s y n D i v ( )
Definition at line 210 of file poly.c.
References bn_poly::dgr.

int bn_poly_quadratic_roots ( register struct bn_complex * roots,

register const struct bn_poly * quadrat

)

Uses the quadratic formula to find the roots (in `complex' form) of any quadratic equation with real coefficients.
q u a d r a t i c ( )
Definition at line 242 of file poly.c.
References bu_log(), LOCAL, NEAR_ZERO, and SQRT_SMALL_FASTF.
Here is the call graph for this function:

HIDDEN void bn_catch_FPE ( int sig )

Definition at line 311 of file poly.c.
References bu_bomb(), bu_is_parallel(), and void().
Referenced by bn_poly_cubic_roots().
Here is the call graph for this function:

int bn_poly_cubic_roots ( register struct bn_complex * roots,

register const struct bn_poly * eqn

)

Definition at line 324 of file poly.c.
References A, Abs, bn_catch_FPE(), bu_is_parallel(), bu_log(), CUBEROOT, FAST, INV_TWENTYSEVEN, LOCAL, PI_DIV_3, SQRT3, SQRT_MAX_FASTF, THIRD, and void().
Here is the call graph for this function:

int bn_poly_quartic_roots ( register struct bn_complex * roots,

register const struct bn_poly * eqn

)

Uses the quartic formula to find the roots ( in `complex' form ) of any quartic equation with real coefficients.
B N _ P O L Y _ Q U A R T I C _ R O O T S

Returns:
1 for success
0 for fail.

Definition at line 431 of file poly.c.
References Abs, bn_poly_cubic_roots(), bn_poly_quadratic_roots(), bn_poly::cf, bn_poly::dgr, LOCAL, and Max3.
Here is the call graph for this function:

void bn_pr_poly ( const char * title,

register const struct bn_poly * eqn

)

B N _ P R _ P O L Y
Definition at line 509 of file poly.c.
References bu_vls_extend(), bu_vls_init(), and bu_vls_strcat().
Here is the call graph for this function:

void bn_pr_roots ( const char * title,

const struct bn_complex * roots,

int n

)

Definition at line 552 of file poly.c.
References bu_log().
Here is the call graph for this function:

Generated on Mon Sep 18 01:25:24 2006 for BRL-CAD by

1.4.6
